Planetary Gearbox - Transmission

Module	Stage	Ratio	Nominal Torque (N·m)	Nominal Input Speed (rpm)	Maximum Radial Load (N)	Maximum Axial Load (N)	Precise Backlash (arcmin)	Noise (dB)
AB-PGT-F42-L1-S□-■	1	4-10	14-23	3000	770	330	3	58
AB-PGT-F42-L2-□-■	2	12-90	14-23	3000	770	330	5	58
AB-PGT-F60-L1-□-■	1	3-10	42-65	3000	1500	700	3	60
AB-PGT-F60-L2-□-■	2	12-90	42-65	3000	1500	700	5	60
AB-PGT-F90-L1-□-■	1	3-10	105-165	3000	3200	1600	3	60
AB-PGT-F90-L2-□-■	2	12-90	105-165	3000	3200	1600	5	60
AB-PGT-F115-L1-□-■	1	3-10	220-345	3000	6700	3300	3	63
AB-PGT-F115-L2-□-■	2	12-90	255-345	3000	6700	3300	5	63
AB-PGT-F142-L1-□-■	1	3-10	450-700	3000	9300	4500	3	65
AB-PGT-F142-L2-□-■	2	12-90	455-700	3000	9300	4500	5	65
AB-PGT-F180-L1-□-■	1	3-10	910-1431	2000	14000	7000	5	67
AB-PGT-F180-L2-□-■	2	12-90	910-1568	2000	14000	7000	7	67
AB-PGT-F220-L1-□-■	1	3-10	1500-2567	2000	16000	8000	5	70
AB-PGT-F220-L2-□-■	2	12-90	1500-2567	2000	16000	8000	7	70
Note: 1. Output Type-□: S1-Shaft; S2-Shaft With Key; S3-Splinde Shaft; K1-Hollow Shaft; K2-Hollow With Key; K3-SWpine hollow; OP3-Case Mounting; OP4-Foot Mounting; 2. Structure -■: R-Rignt Angle; L: Line
